In the electronics supply chain, most of the time on a compliance project lies not in the test room but in collecting material data from suppliers. And most of them fail for a very simple reason: the two sides do not agree on what “material declaration” means.
Buyers only need one line of confirmation to meet the limit; The seller sends a test report with three materials while the product has fifteen materials. As a result, the compliance file has flaws but no one detects them until the end customer or supervisory agency asks questions.
This article explains two commonly used standards for exchanging materials data — IEC 62474 and IPC-1752A — and how to finalize a declaration form that works for both parties.
1. Two standards, two different roles
| Criteria | IEC 62474 | IPC-1752A |
|---|---|---|
| Role | Standard on material declaration content for electrical and electronic products | Standards on forms and how to manage material declarations in the supply chain |
| Focus | List of substances that need to be declared and how to express data | Declaration form, detailed level and exchange process |
| Actual results | Data can be read by the system and reused for many different requests | A form that both parties sign to confirm, suitable for manual and semi-automatic exchanges |
| When to use? | Large supply chains need automatic data exchange between many partners | Small and medium supply chain, exchange for each order |
Point to remember: these two standards are not interchangeable. IEC 62474 is about data content and structure; IPC-1752A is about forms and management. Businesses can use the form according to IPC-1752A with reference substance list IEC 62474.
2. Declarative level classification: why must it be fixed first?
Material declaration is not a single type. In reality, there are many levels, from lightest to heaviest:
- Confirm compliance: a line affirming that the product meets the RoHS limit. Fast, cheap, but has no probative value when questioned.
- Declaration according to the list of restricted substances: declare the concentration of restricted substances in each homogeneous material. This is the most common level for RoHS.
- Declaration according to the expanded list of substances: Add substance groups according to REACH, customer or industry requirements.
- Full declaration of ingredients: List all substances contained in the material, including non-restricted substances. This level is the most labor intensive but can be used for many purposes.
The IPC-1752A standard classifies declaration levels into different groups for consistent naming between parties. The choice of level must be finalized in writing before data collection begins — otherwise, each provider will submit one model.
3. Eight minimum fields should be required in every declaration
| Information field | Why is it necessary? | Common errors |
|---|---|---|
| Supplier material code | Retrieve the correct material being used | Only write the trade name, no code |
| Buyer’s detailed code or product code | Associate data with drawings | Enter product code of different version |
| Declaration date and effective date | Know whether the data is still relevant or not | No date, no version |
| List of homogeneous materials | The limit is applied according to the homogeneous material | Declare all details |
| The concentration of each substance is limited | Compare limits | Just write “pass/fail” |
| Unit of measurement is clear | Avoid confusing % and mg/kg | Do not write units or mix them up |
| Determination method | Indicates whether the data is from experiment or calculation | Write “according to internal documents” |
| Commit to notification when there are changes | The conditions for declaration are still valid | There is no such provision |
4. Why is declared data often not reusable?
Four common problems make declarative data useless when needed:
- Not tied to specific materials: The report says “PC/ABS plastic” but does not specify which plastic is in the product.
- Inconsistent units: Sometimes it’s a percentage, sometimes it’s milligrams per kilogram, sometimes it’s not written.
- Missing timestamp: I don’t know which product version the data belongs to.
- No commitment to notify changes: When the supplier changes the formula, no one knows.
This is the reason why many businesses have to ask for data again every time a customer changes a request, even though it has been collected once before.
5. 6-step process to standardize material declaration
- Make a list of homogeneous materials for products, assign codes to each material.
- Finalize the declaration level need to be collected, clearly stating the list of reference substances.
- Select form shared, clearly state units, expressions, and minimum requirements.
- Issue declaration requests to suppliers with detailed code and response deadline.
- Check input data: If any field is missing, it will be returned, sketchy declarations will not be accepted.
- Save by version and set change notifications for all at-risk materials.
6. Frequently asked questions
Do small businesses need to use these two standards?
It is not necessary to implement it in the form of a data system. But you should use a unified declaration form, based on the minimum fields of the two standards, to avoid asking questions over and over again.
Can material declarations replace test reports?
In many cases yes, if the declaration comes from a verified supplier and is considered trustworthy. But with high-risk materials, there should be periodic confirmatory testing — a declaration is just an assertion.
If the supplier says “RoHS compliant” but doesn’t include data, what should I do?
Requires declaration in a form with minimum fields. If the supplier does not comply, put the material under strict control: screen inputs and test periodically, or find alternative sources.
What is the difference between a material declaration and a declaration of conformity?
Material declarations are technical data about the component, usually issued by the supplier. A declaration of conformity is a legal document signed by the party bringing a product to market, confirming that the product meets applicable requirements. One is the input, the other is the output of the profile.
If the standard version number changes, do I have to re-apply?
It is common for standards to be updated. What needs to be checked is whether the technical requirements and reference substance list have changed compared to existing data; If there is no change in nature, it is usually only necessary to record and update the document.
7. Conclusion
Material declaration is the data infrastructure of regulation compliance. When this infrastructure is standardized, businesses can answer many different types of requirements — RoHS, REACH, unique customer requirements — from the same original data set.
Three things to do immediately: finalize a declaration form with the minimum eight fields; Ask the supplier to clearly state the unit of measurement and effective date; and include a change notification clause in the supply contract.
References
- IEC 62474 — Material declaration for products of and for the electrotechnical industry.
- IPC-1752A — Materials Declaration Management (material declaration form and declaration level).
- Directive 2011/65/EU and its amendments (list of restricted substances, limits based on homogeneous materials).
- Regulation (EC) 1907/2006 (REACH) on the exchange of substance information in supply chains.
